Matrix II Wi-Fi

Matrix II Wi-Fi network controller is designed for using in the online and offline access control systems. It's designed for managemanet of the electromagnetic and electromechanical locks, turnstiles (1 x Matrix II Wi-Fi controllers required). The controller provides power control functionality. Matrix II Wi-Fi controller is easy to install and maintain.

There is a possibility to connect Matrix II Wi-Fi controller to the PC via Wi-Fi network. This makes it possible to build a complete network access control system with a time tracking, event control and report building based on the software solutions.

Matrix II Wi-Fi controller allows you to connect 2 readers, reader and exit button, electromagnetic or electromechanical lock, external buzzer, external LED, door opening sensor.

  • Purpose Lock, Turnstile, Power Control
    Controller type Network
    Connection types Wi-Fi, Micro USB
    Keys count 2024
    Types of recordable keys Normal, Master, Blocking
    Events count 2048
    Key types RFID (Proximity)
    External readers count 2
    External readers protocol iButton (1-Wire), Wiegand-26
    Operating modes (basic) Normal, Blocking, Free, Wait
    Operating modes (advanced) Accept, Evacuation, Anti-Theft, Secure, Gateway, Power Pocket
    Advanced features Double time zones, Key and PIN code access, 2 keys access
    Access point types Door, Gateway, Turnstile, Activator Lock (Gate)
    Actuator types Electromagnetic, Electromechanical, Turnstile
    Built-in reader operating frequency 125 KHz
    Built-in reader standard EM Marine
    Built-in reader reading range (cm) 3–5
  • External readers indication output 1 x 2-colored LED
    Additional power output for external readers No
    Ethernet protocol TCP, IP, ICMP, DHCP, HTTP
    Wi-Fi standard IEEE 802.11b, IEEE 802.11g
    Wi-Fi security algorithm WPA/WPA2, WPA-PSK, WPA2-PSK
    Wi-Fi connection speed 11 Mbps (802.11b), 54 Mbps (802.11g)
    Wi-Fi operating mode Access Point, Client
    Wireless output power (dBm / mW) <20dBm (<100mW)
    USB connection USB Type A
    USB operating mode Host
    Full speed High speed
    Non-volatile memory (EEPROM) Yes
    Voltage 8–24V DC
    Current consumption (mA) 100
    Bleeper Buzzer
    Visual indication 1 x 2-colored LED
    Electromagnetic lock opening duration (s) 0–25.5
    Electromechanical lock opening duration (s) 0–25.5
    MIS transistors count 1
    MIS transistors maximum current (A) 5
    Security alarm output Yes
    Invalid connection protection Yes
    Operating temperature (°C) -30...+40
    Case material ABS polymer
    Dimensions (mm) 85х44х18
