CP-Z 2L Embedded

Compact CP-Z 2L embedded RFID reader is designed for using in the network and standalone access control systems. CP-Z 2L embedded reader supports EM Marine 125KHz keys and connects to the controllers via iButton (1-Wire) or Wiegand-26 protocol.

CP-Z 2L embedded reader is made of mechanically durable and fire-resistant material (polyamide) and repeats the shape of the iButton contactors for DS1990/DS1996 contact keys. It's allows use CP-Z 2L embedded reader in ACS products or independently instead of traditional iButton contactors for contact keys without any design changes or mounting difficulties. It's give you following benefits:

  • Additional RFID technology services and functionality.
  • Advantages of contactless door opening (without taking the key out of your pocket or wallet).
  • Wide choice of RFID keys of various shapes and colors and ability to apply unique logo on the keys.
  • Purpose ACS reader
    Operating frequency 125 KHz
    Key types RFID (Proximity)
    Reader standard EM Marine
    Reader protocol iButton (1-Wire), Wiegand-26
    RFID reading range (cm) 2–6
    Keypad No
    Anti-vandal case Yes
    Waterproof and dustproof case Yes
    Keys copying protection No
  • iButton (1-Wire) maximum line length (m) 15
    Wiegand maximum line length (m) 100
    Voltage 8–18 DC
    Current consumption (mA) 35
    Visual indication 1 x Red LED
    Backlight Red LED continuous lighting (optional)
    External control of LEDs and buzzer No
    Operating temperature (°C) -30...+85
    Case material Polyamide
    Dimensions (mm) D26 x 22
